| Input Parameters | AC frequency: 45-65Hz
AC voltage: 3-phases+(N)+PE, 380/400Vac±10% (CE), 480Vac±10% (NA)
Power factor: >0.99
Total harmonic current: <3% (rated input ) |
|---|
| Output Parameters-EXP180K2-FD | Output DC voltage range: DC 150V-1000V
Max DC output current: 600A@300V/360A@500V/180A@1000V
Max DC output power: 180kW
Constant power voltage range: 300~1000V
Max system efficiency: >95% (rated input and output) |
|---|
| Output Parameters-EXP180K2-FT | Output DC voltage range: DC 150V-1000V
Max DC output current: 600A@300V/360A@500V/180A@1000V
Max DC output power: 180kW
Constant power voltage range: 300~1000V
Max system efficiency: >95% (rated input and output)
AC connector: AC Type 2 32A/22kW/3P |
|---|
| Output Parameters-EXP240K5-FD | Output DC voltage range: DC 150V-1000V
Max DC output current: 600A@400V/480A@500V/240A@1000V
Max DC output power: 240kW
Constant power voltage range: 300~1000V
Max system efficiency: >95.5% (rated input and output) |
|---|
| Working environment | Ambient temperature: -30°C ~ +70°C, full power output below 50°C, power derating 5%/°C above 50°C
Storage temperature: -40°C ~ +75°C
Working humidity: 0-95%
Working altitude: 2000m |
|---|
| Standard | Backend: OCPP 1.6J, support firmware update to 2.0x, OTA support, P&C/smart charge/power management support
CCS PLC communication: DIN70121 and ISO15118
CHAdeMO: CHAdeMO V1.2
GBT: GB/T 18487.1-2015, GB/T 27930-2015, GB/T 20234.1~3-2015
Certification:
cTUVus, Energy Star, TUV CE/ RED, CB, OCA , NMI EICHRECHT for EXP180K2-FD
UL2202, EN61851-21-2 Class A; EN 61851-1/EN 61851-23/EN 61851-24
Protection class: IP55/IK10 (touch screen IK08) |
|---|
| Function and Interface | HMI: Tempered glass protective 7" TFT touch screen LCD, three RGB LED, EPO
Metering: DC energy meter, GB/T 29318 and JJG1149 standard, optional MID and NMI certificatiion meter
Monitor: interface LAN and LTE wireless modem support
Optional CoolRingTM Power transfer: Realize the power transfer between two chargers, each charging connector can get the total charging power
Power switch mode: Intelligent power switch matrix between two DC charging connectors
Payment: RFID, Mobile APP, POS (opt)
MBE function support: WEB side Maintenance Backend System enhances the operation and maintenance effectiveness |
|---|
| Mechanical | Dimensions (W * H * D mm): 700 × 1750 ×750 mm
Weight (kg): 260 kg |
|---|
| Charging Protection | Overcurrent protection, short circuit protection, overvoltage protection, undervoltage protection
Insulation monitoring, Protect earth connect monitoring
Reverse polarity protection, overtemperature protection
RCD-A main protection and RCD-B for AC connector protection |
|---|
| Configuration （Total 6 Power Module Sockets）-EXP180K2-FD | Charger module configuration: REG1K0100G/U 30kW1000V charger power module
Charging connector configuration: 2 * CCS/NACS/GBT or CCS/NACS+GBT/CHAdeMO, optional AC type 2 charging socket
Charging connector capacity: GBT: 250A/400A CCS2: 200A/250A/375A CCS1: 200A/300A NACS: 200A/300A CHAdeMO: 125A/200A AC: 32A/22kW
Optional cable management: Top assemble cable retractors and the light bar |
|---|
| Configuration （Total 6 Power Module Sockets）-EXP180K2-FT | Charger module configuration: REG1K0100G/U 30kW1000V charger power module
Charging connector configuration: 2 * CCS/NACS/GBT or CCS/NACS+GBT/CHAdeMO, optional AC type 2 charging socket
Charging connector capacity: GBT: 250A/400A CCS2: 200A/250A/375A CCS1: 200A/300A NACS: 200A/300A CHAdeMO: 125A/200A AC: 32A/22kW
Optional cable management: Top assemble cable retractors and the light bar |
|---|
| Configuration （Total 6 Power Module Sockets）-EXP240K5-FD | Charger module configuration: REG1K0110U 40kW1000V charger power module
Charging connector configuration: 2 * CCS/NACS/GBT or CCS/NACS+GBT/CHAdeMO, optional AC type 2 charging socket
Charging connector capacity: GBT: 250A/400A CCS2: 200A/250A/375A CCS1: 200A/300A NACS: 200A/300A CHAdeMO: 125A/200A AC: 32A/22kW
Optional cable management: Top assemble cable retractors and the light bar |
|---|
